Contactless rotary torque sensor Shaft torque transducer with speed measurement

Contactless rotary torque sensor Shaft torque transducer with speed measurement

    • Contactless rotary torque sensor Shaft torque transducer with speed measurement
    • Contactless rotary torque sensor Shaft torque transducer with speed measurement
    • Contactless rotary torque sensor Shaft torque transducer with speed measurement
  • Contactless rotary torque sensor Shaft torque transducer with speed measurement

    Product Details:

    Place of Origin: China
    Brand Name: Forsentek
    Model Number: FYTD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pc
    Packaging Details: Shockproof packing
    Delivery Time: 3-15 working days
    Payment Terms: Western Union, T/T,Paypal, MoneyGram
    Supply Ability: 3000pcs/month
    Contact Now
    Detailed Product Description
    Type: Contactless Torque Transducer Capacity: 5NM 10NM 20NM 30NM 50NM 100NM
    Output: ±5V/±10V/4-20mA Application: Rotating Torque Speed Measurement

    Contactless rotary torque sensor Shaft torque transducer with speed measurement

    Contactless rotary torque sensor FYTD measures both torque and rotating speed with ±5V /±10V / 4-20mA output.Contactless rotary torque transducer FYTD offers 5NM / 10NM / 20NM / 30NM / 50NM / 100NM six measuring ranges with maximum 0.2% non-linearity of the full capacity to choose from,rotating speed measurement goes up to 6000RPM,and it is more durable compared to slip-ring type torque transducers thanks to non-contact transformer technology. Shaft to shaft configuration, can be easily installed through couplings, the housing remains still while the shaft rotates during measurement, it is also applicable for torsion measurement cases with low rotating speed. Typical applications for FYTD is such as motor test benches, tightening torque monitoring, rotating torque measurement for servo motors, pumps, gearbox, engines, agitators,etc..


    contactless rotary torque sensor
    Specifications

    Capacity 5NM 10NM 20NM 30NM 50NM 100NM
    Rated output ±5V / ±10V / 4-20mA
    Excitation 24V DC (or 12V DC)
    Zero balance ±2% R.O.
    Nonlinearity ±0.2% R.O.
    Hysteresis ±0.2% R.O.
    Nonrepeatability ±0.2% R.O.
    Creep(10min) ±0.1% R.O.
    Safe overload 150% F.S.
    Ultimate overload 200% F.S.
    Operating temp. -10...+60oC
    Ingress protection IP50
    Material of element Stainless steel
    Material of housing Aluminum
    Cable Ø6*3000mm(Mating connector provided)



    Shaft to shaft contactless rotary torque sensor 100NM 50NM 30NM 20NM 10NM 5NM

    contactless rotary torque transducer

    Dimensions:

    rotary torque transducer with speed encoder

    contactless torque sensor pdf
