| Place of Origin: | China |
| Brand Name: | Forsentek |
| Certification: | CE |
| Model Number: | FMZT |
| Minimum Order Quantity: | 1pc |
|---|---|
| Packaging Details: | Shockproof carton |
| Delivery Time: | 3-20 working days |
| Payment Terms: | T/T, Western Union, MoneyGram,Paypal |
| Supply Ability: | 49760pcs/month |
| Material: | Aluminum | Output: | Analog |
|---|---|---|---|
| Usage: | Weight Measurement | Length: | 30mm |
| Range: | 0-2kg | Type: | Micro Load Sensor |
Small Size Load Cell Transducer 2kg Micro Weighing Sensor 20N
Micro Load Sensor FMZT is strain gauge based intended for weight measurement within range of 0-2kg. Miniature Loadcell utilizes 1000 ohms high resistance strain gauges,which is more energy-efficient and has better stability in the long run compared to commonly used 350 ohms strain gages. Aluminum construction, lightweight design with only 3.3 grams self-weight, miniature weight sensor FMZT is suitable for portable weighing devices. You may find weight transducer FMZT applicable for weight monitoring & controlling in smart coffee machine, force simulators,home appliances, portable force measuring devices, game consoles,and so on.If you are looking for similar weighing sensors with different measuring ranges,custom made service is also available at Forsentek.
Specifications
| Rated capacity |
2kg / 20N / 4.4lb Customizable |
||
| Sensitivity | 0.7 mV/V | Compensated temperature | 0...+40oC |
| Excitation | 3-10V | Operating temperature | -10...+50oC |
| Zero balance | ±0.1mV/V | Temperature shift zero | ±0.2% R.O./oC |
| Nonlinearity | ±0.1% R.O. | Temperature shift span | ±0.01% R.O./oC |
| Hysteresis | ±0.1% R.O. | Input resistance | 1000±100 ohms |
| Nonrepeatability | ±0.1% R.O. | Output resistance | 1000±100 ohms |
| Creep(2min) | ±0.1% R.O. | Insulation resistance | >2000Mohms |
| Safe overload | 150% F.S. | Ingress protection | IP50 |
| Ultimate overload | 200% F.S. | Material of element | Aluminum |
| Cable | AWG32*50mm(Longer cable upon request) | ||
| Wiring code |
Red--Power input+ Black--Power input- Green--Signal output+ White--Signal output- |
||
Overloading is the most common cause of load sensor failure, a loadcell is just like a spring in certain aspects, which will be damaged if overstretched or overloaded. A machanical stop(refer to below picture) can be used to protect the sensor from excessive deformation. The deformation distance can be determined by loading the sensor with rated capacity, then adjust the meachnical stop to reach the bottom of the transducer. In most cases, the load transducer will be used to measure load at 40-80% of the full scale, thus the deformation distance can be adjusted using reference load which is a bit higher than the maximum target load to be measured instead of the rated capacity.
